HRS Steel S235JR (Hot Rolled Structural Steel) at CutWise

HRS Steel S235JR (Hot Rolled Structural Steel)

Metals

HRS Steel S235JR is a hot rolled structural steel widely used in the manufacturing, construction, and engineering industries. Known for its excellent weldability, machinability, and cost-effectiveness, S235JR is the ideal choice for structural components, frames, brackets, and general fabrication. Its combination of strength and ease of processing makes it one of the most commonly specified structural steels in Europe.
S235JR is manufactured according to the EN 10025-2 standard and is often referred to as Hot Rolled Steel (HRS), Structural Steel S235JR, or simply Mild Steel S235JR. We supply high-quality HRS Steel S235JR for a wide range of industrial applications with precise cutting tailored to your specifications.

Laser cutting
Milling

Calculate price directly

Properties of HRS Steel S235JR

Excellent weldability without requiring special procedures
Good machinability for efficient manufacturing
High toughness and impact resistance at room temperature
Suitable for structural and load-bearing applications
Cost-effective material for general engineering projects
Good formability for bending and fabrication
Available in a wide range of thicknesses
Compatible with various surface treatments such as galvanizing, painting, and powder coating
Manufactured according to EN 10025-2 quality standards

These balanced properties make S235JR one of the most versatile structural steels for machine building, construction, and industrial manufacturing.

Datasheet Title

Technical properties of HRS Steel S235JR

Download datasheet

Product information and operations

Thickness	Dimensions	Laser cutting	Milling	Bending
4 mm	3000x1500 mm
5 mm	3000x1500 mm
6 mm	3000x1500 mm
8 mm	3000x1500 mm
10 mm	3000x1500 mm
12 mm	3000x1500 mm
15 mm	3000x1500 mm
20 mm	3000x1500 mm

Technical properties

General

Material Standard EN 10025-2

Material Grade S235JR

Material Type Hot Rolled Structural Steel

Density 7.85 g/cm³

Mechanical

Yield Strength ≥ 235 MPa

Tensile Strength 360–510 MPa

Elongation ≥ 26%

Hardness Approx. 120 HB

Electrical

Electrical Conductivity Approx. 6–7 MS/m

Electrical Resistivity Approx. 0.15 µΩ·m

Thermal

Thermal Conductivity Approx. 50 W/m·K

Specific Heat Capacity Approx. 470 J/kg·K

Coefficient of Thermal Expansion 12 × 10⁻⁶ /K

Temperature Range

Recommended Operating Temperature -20°C to +400°C

Impact Test Temperature (JR) 27 J at +20°C

Applications of HRS Steel S235JR

Machine frames and machine components

Structural steel constructions

Mounting plates and base plates

Industrial brackets and supports

Conveyor systems and material handling equipment

Agricultural machinery

Automotive and transport components

General fabrication and engineering projects

Made with CutWise

Frequently Asked Questions about HRS Steel S235JR

What is HRS Steel S235JR?

HRS Steel S235JR is a hot rolled non-alloy structural steel grade specified in EN 10025-2. It is widely used for structural and engineering applications due to its excellent weldability, machinability and cost-effective performance.

What does the "JR" designation mean?

The "JR" classification indicates that the steel achieves a minimum Charpy impact value of 27 Joules at +20°C, ensuring reliable toughness under standard operating conditions.

Is S235JR suitable for laser cutting?

Yes. HRS Steel S235JR is highly suitable for laser cutting. It produces clean, accurate cuts with excellent edge quality, making it ideal for precision-manufactured components.

Can S235JR be milled?

Yes. S235JR has good machinability and is well suited for milling operations. It can be accurately machined to produce finished components with tight tolerances.

Is S235JR easy to weld?

Yes. One of the key advantages of S235JR is its excellent weldability. It can be welded using conventional welding processes without requiring special procedures in most applications.

Can S235JR be galvanized?

Yes. S235JR is commonly hot-dip galvanized or coated with paint or powder coating to improve corrosion resistance for outdoor and industrial environments.

What is the difference between S235JR and S355MC?

S235JR is a general-purpose structural steel designed for standard engineering and fabrication work. S355MC is a high-strength thermo-mechanically rolled steel with significantly higher yield strength, making it better suited for lightweight structures, vehicle chassis and demanding load-bearing applications.

Which industries commonly use S235JR?

S235JR is widely used in machine building, manufacturing, construction, material handling, agricultural equipment, automotive production and general metal fabrication because of its versatility, availability and ease of processing.
